Toro

Electric PTO Clutch 5215-59

Add to cart
STE255-547

DESCRIPTION
Xtreme Electric PTO Clutch
Xtreme X0185
REPLACES OEM:
AYP: 16343, 19982, 53679
Bolens: 717-0983, 717-3497, 917-0983, 917-3497
Case: 990947
Craftsman: 16343, 1703816SM, 19982, 53679, 7016343, 7053679, 717-0983, 717-3497, 917-0983, 917-3497
Cub Cadet: 717-0983, 717-3497, 917-0983, 917-3497
Jacobsen: 990947
MTD: 717-0983, 717-3497, 917-0983, 917-3497
New Holland: 990947
Simplicity: 1703816, 1703816SM, 71703816
Snapper: 16343, 19982, 53679, 7016343, 7053679, 7053679yp
Toro: 11346, 99-8012
Troy-Bilt: 717-3036, 717-3497, 917-3497, 959-3230
Warner: 5210-33, 5215-59
White: 717-0983, 717-3497, 917-0983, 917-3497
Xtreme: X0185
FITS MODELS:
Bolens: FST14, FST15, LR13, LT14, LT145, LT15, LT16 and LT165
Simplicity: 1613G, 1615G, 1613H, 1615H, 1616H, 2614H, 2616H, Broadmoor, LT, LTG and LTH series
Snapper: GT180, GYT, HT, LT, RYT, YT, PL7H and PP7H series
SPECS:
ID: 1"
Diameter Pulley: 5 5/16"
Direction: Counter clockwise
Uses belt width: 1/2" or 5/8"
Installation: To prevent premature clutch failure, follow the instruction sheet included with the clutch
Cool Coil Technology
High Temperature Bearing Upgrade
Replaceable Pulley Bearing
Super Smooth "Xtreme Precision" Machined Pulley
Integrated Water Tight Wire Harness


Electric PTO Clutch 5215-62

Add to cart
STE255-519

DESCRIPTION
Xtreme Electric PTO Clutch
Xtreme X0450
REPLACES OEM:
Ariens: 03090800, 30908
Case: C38410
Craftsman: C38410, WD-C38410
Cub Cadet: C38410, WD-C38410
Grasshopper: 388766, 604182
Gravely: 03090800, 30908
Jacobsen: C38410
MTD: C38410, WD-C38410
New Holland: C38410, WD-C38410
Toro: 93-3160
Warner: 5210-52, 5215-120, 5215-62
White: C38410, WD-C38410
Woods: 388766, 604182
Xtreme: X0450
FITS MODELS:
Ariens: 931037, 931038, 931302, 931303 and 987104
Grasshopper: 718K and 720K
Gravely: 931037, 931038, 931302, 931303 and 987104
Toro: 74140 and Proline 724-Z, Serial No. 590001-699999
SPECS:
ID: 1 1/8"
Diameter Pulley: 4 13/16"
Direction: Clockwise
Cool Coil Technology
Heavy Duty "FatBoy Series" Upgrade
Replaceable Pulley Bearing
Super Smooth "Xtreme Precision" Machined Pulley
Upgraded to 3 Layer "Xtreme TOUGH" Integrated, Water Tight Wire Harness

Electric PTO Clutch 5215-88

Add to cart
STE255-323

Replaces (OEM): ARIENS 03450500
DIXIE CHOPPER 50300
SNAPPER 7-9197
SNAPPER 7-9446
SNAPPER 7079446
TORO 116277
WARNER 5215-88
ID: 1"
Height: 3 1/2"
Diameter Pulley: 5 3/8"
Direction: Clockwise
Uses belt width: 1/2"
  Made by an OEM suppli

Electric PTO Clutch 5217-35

Add to cart
STE522-511
REPLACES OEM:
Ariens: 03643100,
AYP: 160889, 532160889, 53740,
Bolens: 1772388, GW-1772388,
Cub Cadet: 1772388, 717-1459, 917-1459, GW-1772388,
Dixon: 160889, 532160889,
Exmark: 104-3334,
Gravely: 03643100,
Husqvarna: 532160889,
John Deere: AM119683,
Jonsered: 160889, 532160889,
Kees: 160889,
MTD: 1772388, 717-1459, 917-1459,
Snapper: 5-3740, 7053740,
Swisher: 688EC,
Toro: 104-3334,
Troy-Bilt: 1772388, 717-1459, 917-1459,
Warner: 5217-35, 5217-6, 5217-9,
Woods: 03643100,
FITS MODELS:
SPECS:
ID: 1"
Height: 3"
Diameter Pulley: 5 3/8"
Direction: Counter clockwise
Uses belt width: 1/2" or 5/8"
Designed For: Rugged use
For Proper Ordering: Reference Warner or Ogura part numbers stamped on clutch
Made By: An OEM supplier
Clutch Applications: Residential and commercial
Torque Correctly: To prevent premature failure

Electric PTO Clutch 5218-10

Add to cart
STE255-331

Replaces (OEM): ARIENS 09225400
COUNTRY CLIPPER E-6247
DIXON 61516
GRAVELY 09225400
TORO 94-6136
WARNER 5218-10
ID: 1 1/8" ID
Height: 3 1/4"
Diameter Pulley: 5 3/8"
Direction: Counterclockwise
Uses belt width: 1/2" OR 5/8"
  Made by an OEM supplier

Electric PTO Clutch 5218-65

Add to cart
STE255-552

REPLACES OEM:
Bobcat: 2721337,
Bunton: 2721337,
Case: 2721337,
Exmark: 1-631732, 1-641300, 103-0501, 103-0665, 631732, 641300, E631732,
Great Dane: 180265,
Jacobsen: 2721337,
Toro: 1-631732, 1-641300, 103-0501, 103-0665, 631732, E631732,
Warner: 5218-213, 5218-65, 5218-65E,
FITS MODELS:
SPECS:
ID: 1 1/8"
Height: 3 5/8"
Diameter Pulley: 6 5/16"
Direction: Clockwise
Uses belt width: 5/8"
Designed For: Rugged use
For Proper Ordering: Reference Warner or Ogura part numbers stamped on clutch
Made By: An OEM supplier
Clutch Applications: Residential and commercial
Torque Correctly: To prevent premature failure

Electric PTO Clutch 5218-76

Add to cart
STE255-399
33-135

REPLACES OEM:
Exmark: 1-631644, 1-631731, 1-633098, 103-0500, 103-0661, 631644, 631731, 633098, E631644, E631731, E633098,
Toro: 1-631644, 1-631731, 1-633098, 1-641213, 103-0500, 103-0660, 103-0661, 103-0662, 631644, 631731, 633098, E631644, E631731, E633098,
Warner: 5218-21, 5218-25, 5218-293, 5218-76, 5218-76C,
FITS MODELS:
Exmark: Lazer Z
SPECS:
ID: 1"
Height: 3 5/16"
Diameter Pulley: 6 5/16"
Direction: Clockwise
Uses belt width: 5/8"
Pigtail: Included
Designed For: Rugged use
For Proper Ordering: Reference Warner or Ogura part numbers stamped on clutch
Made By: An OEM supplier
Clutch Applications: Residential and commercial
Torque Correctly: To prevent premature failure

Electric PTO Clutch 5218-201

Add to cart
STE255-560
Replaces (OEM): EXMARK 1-65304
EXMARK 1-653048
EXMARK 1-653292
EXMARK 103-0690
EXMARK 109-2916
EXMARK 109-9276
EXMARK 653048
TORO 105-3630
WARNER 5218-201
WARNER 5218-215
WARNER 5218-44
WARNER 5218-80
WARNER I-5218-80-C
WRIGHT MFG 71410013
Fits Models: EXMARK Lazer HP and Lazer; for 17 HP Kawasaki engines
Specs:
  • ID:1"
  • Height:3 1/4"
  • Diameter Pulley:7 1/4"
  • Direction:Counter clockwise
  • Uses belt width:5/8"

Electric PTO Clutch 5218-213

Add to cart
STE255-552

Replaces (OEM): BAD BOY 070-5035-00
BOBCAT 2721337
EXMARK 1-631732
EXMARK 1-641300
EXMARK 103-0665
GRASSHOPPER 388740
HUSTLER 787366
TORO 103-0501
WARNER 5218-213
WARNER 5218-65
WARNER 5218-65 E
Specs:

1-1/8"ID x 6-3/8" Pulley

Electric PTO Clutch 5219-81

Add to cart
STE255-823
Replaces OEM:
  • EXMARK: 110-6766
  • Internal - Stens: 255823
  • TORO: 110-6766
  • WARNER: 5219-81
Fits Models:
  • EXMARK Quest
  • TORO Titan and Time Cutter
Specs:
  • Height: 3.6 "
  • ID: 1 "
  • Diameter Pulley: 5.8 "
  • Direction: Counter clockwise
  • Uses belt width: 1/2 "
  • Adjustment and maintenance free
  • Designed for rugged use
  • For proper ordering, reference Warner or Ogura part number stamped on clutch
  • Made by an OEM supplier
  • Residential and commercial applications
  • Torque correctly to prevent premature failure

Electric PTO Clutch 5219-172

Add to cart
STE255-869
255-869
REPLACES OEM:
Toro: 127-3408,
Warner: 5219-172,
FITS MODELS:
SPECS:
ID: 1"
Height: 3"
Diameter Pulley: 5 3/4"
Direction: Counter clockwise
Uses belt width: 1/2"
Designed For: Rugged use
For Proper Ordering: Reference Warner or Ogura part numbers stamped on clutch
Made By: An OEM supplier
Clutch Applications: Residential and commercial
Torque Correctly: To prevent premature failure

Electric PTO Clutch MA-GTEXM14

Add to cart
STE255-527

Replaces (OEM): EXMARK 1-631732
EXMARK 1-641300
EXMARK 103-0665
FERRIS 1521145
OGURA GT2.5-MC04
OGURA MA-GTEXM14
SCAG 461395
SCAG 461716
SCAG 481530
Fits Models: EXMARK Lazer Z
ID: 1 1/8"
Height: 2 3/4"
Diameter Pulley: 6"
