Simplicity

Xtreme PTO Clutch 5210-33

Add to cart
STEX0185

DESCRIPTION
Xtreme PTO Clutch
MTD 917-3497
REPLACES OEM
  • AGCO1703816SM
  • Bolens717-0983, 717-3497, 917-0983, 917-3497
  • CaseIH990947
  • Craftsman16343, 1703816SM, 19982, 53679, 7016343, 7053679, 717-0983, 717-3497, 917-0983, 917-3497
  • Cub Cadet717-0983, 717-0983P, 717-3497, 917-0983, 917-3497
  • Ingersoll Rand990947
  • Jacobsen990947
  • King Cat232201
  • MTD1755341P, 717-0983, 717-0983P, 717-3497, 917-0983, 917-3497
  • Simplicity1703816, 1703816SM, 71703816
  • Snapper16343, 19982, 53679, 7016343, 7053679, 7053679YP
  • Toro113426, 11346, 99-8012
  • Troy-Bilt717-3036, 717-3497, 917-3497, 959-3230
  • Warner5210-33, 5215-59
  • White717-0983, 717-3497, 917-0983, 917-3497
FITS MODELS
  • BolensFST14, FST15, LR13, LT14, LT145, LT15, LT16 and LT165
  • Cub Cadet1110, 1105, 1215, 1220, 1225, 1325, 1405, 1415, 1420, 1605, 1610, 1615, 1620, 1715, 1720 and 1730
  • Ford9800686
  • Lawn-Boy156729, 52140, 52144A, 52145A, 52153, 52161, 52163, 52163A and 52164, 1991-1992
  • MTDFST14, FST15, LT13, LT14, LT15, LT16, LT145 and LT165
  • Simplicity1613G, 1613H, 1615G, 1615H, 1616H, 2614H, 2616H, LT, LTG and LTH series
  • SnapperGT180, GYT, HT, LT, RYT and YT series
    • SPECS
  • Cool Coil Technology
  • Does not fit all applications - Verify part number by referring to model specifications
  • High Temperature Bearing Upgrade
  • Integrated Water Tight Wire Harness
  • Replaceable Pulley Bearing
  • Super Smooth "Xtreme Precision" Machined Pulley
  • To prevent premature clutch failure, follow the instruction sheet included with the clutch
  • Belt Width1/2" or 5/8"
  • ID1"
  • Pulley Diameter5 5/16"
  • Rotation DirectionCounter Clockwise

    • Xtreme PTO Clutch 5215-13

    Add to cart
    STEX0165

    DESCRIPTION
    Xtreme PTO Clutch
    Exmark 1-603539
    REPLACES OEM
    • Exmark1-601979, 1-603463, 1-603539, 1-611190, 1-611223, 601979, 603463, 603539, 611190, 611223
    • Ferris1521823, 21823, 5021823
    • Scag461074, 481633, 48786
    • Simplicity1521823, 21823, 21823SM, 5021823, 5021823SM
    • Snapper21823, 2840890, 29678, 5021823, 7029678, 7029678YP
    • Snapper Pro21823, 29678, 5021823, 7029678
    • Warner5215-13, 5215-99
    FITS MODELS
  • ExmarkTurf Ranger 1800, Turf Tracer 5-Speed, Serial No. 89,999 and lower and Turf Tracer Hydro, Serial No. 70,000-129,999 and 190,000-319,999
  • Ferris5900027, 5900030, 5901009, 5901012, 5901014, 5901015, 5901194, BGF36K, BGF52K and UltraBelt GD series
  • ScagSSZ, STHM, SW and SWZ series
  • Snapper7080717, 7080682, 7080683, 7080685, 7080686, 7080687 and 7080695
  • Snapper Pro7080682, 7080683, 7080685, 7080686, 7080687, 7080695 and 7080717
    • SPECS
  • Cool Coil Technology
  • Does not fit all applications - Verify part number by referring to model specifications
  • High Temperature Bearing Upgrade
  • Integrated Water Tight, Impact Resistant Wire Harness
  • Replaceable Pulley Bearing
  • Super Smooth "Xtreme Precision" Machined Pulley
  • To prevent premature clutch failure, follow the instruction sheet included with the clutch
  • Belt Width1/2" or 5/8"
  • ID1"
  • Pulley Diameter6"
  • Rotation DirectionClockwise

    • Xtreme PTO Clutch 5215-22

    Add to cart
    STEX0174

    DESCRIPTION
    Xtreme PTO Clutch
    Simplicity 1706692SM
    REPLACES OEM
    • Simplicity1706692, 1706692SM
    • Warner5215-22
    FITS MODELS
  • Simplicity1717H, 1718H, 1720H, 2720H, 2718H, 2723H, GTG, GTH and Landlord series
    • SPECS
  • Cool Coil Technology
  • Does not fit all applications - Verify part number by referring to model specifications
  • Heavy Duty "FatBoy Series" Upgrade
  • Replaceable Pulley Bearing
  • Super Smooth "Xtreme Precision" Machined Pulley
  • To prevent premature clutch failure, follow the instruction sheet included with the clutch
  • Upgraded to 3 Layer "Xtreme TOUGH" Integrated, Water Tight Wire Harness
  • Belt Width1/2" or 5/8"
  • ID1"
  • Pulley Diameter5 5/16"
  • Rotation DirectionCounter Clockwise

    • Xtreme PTO Clutch 5217-2

    Add to cart
    STEX0002
    DESCRIPTION
    Xtreme PTO Clutch
    Husqvarna 532145028
    REPLACES OEM
    • Ariens03601800
    • AYP145028, 532145028
    • Craftsman145028, 1686882, 1686882S, 1686882SM, 1708536, 1708536SM, 532145028
    • Dixon145028, 532145028
    • Electrolux145028, 532145028
    • Gravely03601800
    • Husqvarna145028, 532145028
    • Kees145028, 532145028
    • Massey Ferguson145028, 1686882, 1686882S, 1686882SM, 532145028
    • McCulloch145028, 1686882, 1686882S, 1686882SM, 532145028
    • Poulan145028, 532145028
    • Simplicity1686882, 1686882S, 1686882SM, 1708536, 1708536SM
    • Snapper1686882, 1686882S, 1686882SM, 1708536, 1708536SM
    • Snapper Pro1686882, 1686882S, 1686882SM
    • Warner5217-2, 5217-46
    FITS MODELS
  • AriensEZR, LT, Sierra and YT series
  • CraftsmanCO, CT, DB, DPR, PP, PR, QP, RE, RK, YG and YP series
  • GravelyGLT440 and GLT448
  • HusqvarnaGTVH200, 1998-2010, GTVH205, 1999-2010, YTH180, 954140010E, 1998-2006, YTH1342XP, YTH1542XPA, YTH1542XPB, YTH1542XPC, YTH1542XPD, YTH1542XPE, YTH1542XPF, YTH1542XPG, YTH2046A, YTH2046B, YTHK1542XPA, YTHK1542XPB and YTHK1542XPC
  • SearsCO, CT, DB, DPR, PP, PR, QP, RE, RK, YG and YP series
  • Simplicity400, Coronet, Regent and ZT series
  • SnapperRT1330, RT1330E and RT1330E Hydro
  • Snapper ProRT1330, 30" deck, hydro drive series 0
    • SPECS
  • Cool Coil Technology
  • Does not fit all applications - Verify part number by referring to model specifications
  • Heavy Duty "FatBoy Series" Upgrade
  • Integrated Water Tight Wire Harness
  • Replaceable Pulley Bearing
  • Super Smooth "Xtreme Precision" Machined Pulley
  • To prevent premature clutch failure, follow the instruction sheet included with the clutch
  • Belt Width1/2" or 5/8"
  • ID1"
  • Pulley Diameter5 3/8"
  • Rotation DirectionCounter Clockwise

    • Xtreme PTO Clutch 5218-221

    Add to cart
    STEX0245

    DESCRIPTION
    Xtreme PTO Clutch
    Simplicity 5100084SM
    REPLACES OEM
    • Craftsman5100084, 5100084S, 5100084SM
    • Ferris5100084, 5100084S, 5100084SM
    • Massey Ferguson5100084, 5100084S, 5100084SM
    • McCulloch5100084, 5100084S, 5100084SM
    • Simplicity5100084, 5100084S, 5100084SM
    • Snapper5100084, 5100084S, 5100084SM
    • Snapper Pro5100084, 5100084S, 5100084SM
    • Warner5218-221
    FITS MODELS
  • FerrisEvolution with 36", 48" and 52" deck, F50XT series with 36" deck, F150XT series with 52", F200XT series with 61" deck, Flail series, IS1500Z, IS1500ZX, IS2000Z and Procut S series
  • Massey Ferguson3000 and 3900 series
  • SimplicityCitation Series 5900522, 5900523, 5900524, 5900525, 5900526, 5900527, 5900530, 5900531, 5900762, 5900764, 5900820, 5900821, 5900954 and 2690479
  • SnapperS50X, S50XT, S75X, S125XT, S150X, S200X, S200XT, SW30KAV and SW35KAV series
  • Snapper ProS50XT, S75XT, S150XT, S200XT and SW30 series
    • SPECS
  • Cool Coil Technology
  • Does not fit all applications - Verify part number by referring to model specifications
  • Heavy Duty "FatBoy Series" Upgrade
  • Replaceable Pulley Bearing
  • Super Smooth "Xtreme Precision" Machined Pulley
  • To prevent premature clutch failure, follow the instruction sheet included with the clutch
  • Upgraded to 3 Layer "Xtreme TOUGH" Integrated, Water Tight Wire Harness
  • Belt Width1/2" or 5/8"
  • ID1 1/8"
  • Pulley Diameter6 5/16"
  • Rotation DirectionCounter Clockwise

    • Xtreme PTO Clutch GT1-BS03

    Add to cart
    STEX0486

    DESCRIPTION
    Xtreme PTO Clutch
    Murray 1687746YP
    REPLACES OEM
    • Briggs & Stratton1686880SM, 1687746YP
    • Craftsman1686880, 1686880SM
    • Murray1686880, 1686880SM, 1687746YP
    • OguraGT1BS03, GT1-BS03
    • Simplicity1686880, 1686880SM, 1687746, 1687746YP, 1717664SM, 1720532, 1720532SM
    • Snapper1686880, 1686880SM, 1687746, 1687746YP, 1717664, 1717664SM, 1720532
    FITS MODELS
  • MurrayEZT2042, ZT1644E, ZT7000, ZTS6000 and ZTX7500
  • SimplicityBaron, Baron XL, Braodmoor, Conquest, Pacer, Rapid and Regent series
  • Snapper150Z, 200Z, 285Z, 300Z, RD, RZT, YT and ZT series; EZT2042, LT2246, YT2452, ZT2446 and ZT2752
    • SPECS
  • Does not fit all applications - Verify part number by referring to model specifications
  • Heavy Duty "FatBoy Series" Upgrade
  • High Torque Cool Coil Upgrade
  • Integrated Water Tight Wire Harness
  • Replaceable Pulley Bearing
  • Super Smooth "Xtreme Precision" Machined Pulley
  • To prevent premature clutch failure, follow the instruction sheet included with the clutch
  • Belt Width1/2" or 5/8"
  • ID1"
  • Pulley Diameter5 5/16"
  • Rotation DirectionCounter Clockwise

    • Xtreme PTO Clutch GT1-FE01S

    Add to cart
    STEX0613

    DESCRIPTION
    Xtreme PTO Clutch
    Simplicity 5023432SM
    REPLACES OEM
    • Ferris5022584, 5023231, 5023432, 5023432SM
    • OguraGT2.5-FE01S, GT25FE01S
    • Simplicity5023432, 5023432SM
    • Snapper5023432, 5023432SM
    FITS MODELS
  • SimplicityCitation series, Colt ZT2148T, Colt ZT2348T and Colt ZT2352T
    • SPECS
  • Cool Coil Technology
  • Does not fit all applications - Verify part number by referring to model specifications
  • High Temperature Bearing Upgrade
  • Replaceable Pulley Bearing
  • Super Smooth "Xtreme Precision" Machined Pulley
  • To prevent premature clutch failure, follow the instruction sheet included with the clutch
  • Water Tight, Replaceable Wire Harness Pigtail
  • Belt Width1/2" or 5/8"
  • ID1 1/8"
  • Pulley Diameter6 7/16"
  • Rotation DirectionCounter Clockwise

    • Xtreme PTO Clutch GT2.5-MC04

    Add to cart
    STEX0616

    DESCRIPTION
    Xtreme PTO Clutch
    Exmark 103-0665
    REPLACES OEM
    • Exmark103-0663, 103-0665, 1-641212, 1-641300, 641212, 641300
    • Ferris1521145, 5021145, 5021145SM
    • OguraGT2.5-MC04, GT25MC04, MAGTEXM14, MA-GT-EXM14
    • Scag461395, 461409, 461716
    • Simplicity5021145, 5021145SM
    • Toro641299
    FITS MODELS
  • ExmarkLazer Z series
  • FerrisHydro Drive, HydroWalk DD, HydroWalk and ProCut series
    • SPECS
  • Cool Coil Technology
  • Does not fit all applications - Verify part number by referring to model specifications
  • High Temperature Bearing Upgrade
  • High Torque Cool Coil Upgrade
  • Replaceable Pulley Bearing
  • Super Smooth "Xtreme Precision" Machined Pulley
  • To prevent premature clutch failure, follow the instruction sheet included with the clutch
  • Water Tight, Replaceable Wire Harness Pigtail
  • Belt Width1/2" or 5/8"
  • ID1 1/8"
  • Pulley Diameter6 1/16"
  • Rotation DirectionClockwise

    • Xtreme PTO Clutch GT2.5-SN01

    Add to cart
    STEX0600

    DESCRIPTION
    Xtreme PTO Clutch
    Snapper 7075672YP
    REPLACES OEM
    • OguraGT2.5-SN01, GT25SN01
    • Simplicity7075672YP
    • Snapper7075081, 7075672, 7075672YP, 75672
    • Snapper Pro7075081, 7075672, 7075672YP
    FITS MODELS
  • SnapperPro series 1, 2 and 3 Joystick
    • SPECS
  • Cool Coil Technology
  • Does not fit all applications - Verify part number by referring to model specifications
  • High Temperature Bearing Upgrade
  • Replaceable Pulley Bearing
  • Super Smooth "Xtreme Precision" Machined Pulley
  • To prevent premature clutch failure, follow the instruction sheet included with the clutch
  • Upgraded to 3 Layer "Xtreme TOUGH" Water Tight, Replaceable Wire Harness
  • Belt Width1/2" or 5/8"
  • ID1"
  • Pulley Diameter6"
  • Rotation DirectionCounter Clockwise

    • Xtreme PTO Clutch GT-JD11

    Add to cart
    STEX0487

    DESCRIPTION
    Xtreme PTO Clutch
    Snapper 1757359YP
    REPLACES OEM
    • Ferris1757359
    • Murray1757359YP
    • OguraMAGTJD11, MA-GT-JD11
    • Simplicity1757359YP
    • Snapper1757359YP
    • Snapper Pro1757359
    FITS MODELS
  • Ferris5900111, 5900543, 5900544, 5900545, 5900546, 5900604, 5900962, 5900963, 5900989, 5900990 and 5901037
  • SimplicityAxion 78007600, 7800380 and 7800360
  • Snapper2691043-03, 2691043-04, 2691166-00, 2691136-00, 2691136-01, 2691135-00, 2691137-00, 2691137-01, 2691164-00, 2691165-00 and 2691167-00
  • Snapper Pro5900895 and 5900896 SW series, Serial No. 2016545302 and lower
    • SPECS
  • Does not fit all applications - Verify part number by referring to model specifications
  • Heavy Duty "FatBoy Series" Upgrade
  • High Torque Cool Coil Upgrade
  • Integrated Water Tight Wire Harness
  • Replaceable Pulley Bearing
  • Super Smooth "Xtreme Precision" Machined Pulley
  • To prevent premature clutch failure, follow the instruction sheet included with the clutch
  • Belt Width1/2" or 5/8"
  • ID1"
  • Pulley Diameter5 5/16"
  • Rotation DirectionCounter Clockwise
