Scag

Xtreme PTO Clutch 461660

STEX0660

DESCRIPTION
Xtreme PTO Clutch
Scag 461660
REPLACES OEM
  • Scag461660
FITS MODELS
  • ScagTiger Cub and Wildcat series
    • SPECS
  • Does not fit all applications - Verify part number by referring to model specifications
  • High Temperature Bearing Upgrade
  • High Torque Cool Coil Upgrade
  • Replaceable Pulley Bearing
  • Super Smooth "Xtreme Precision" Machined Pulley
  • To prevent premature clutch failure, follow the instruction sheet included with the clutch
  • Upgraded to 3 Layer "Xtreme TOUGH" Water Tight, Replaceable Wire Harness
  • Belt Width1/2" or 5/8"
  • ID1 1/8"
  • Pulley Diameter6"
  • Rotation DirectionClockwise

    • Xtreme PTO Clutch 5215-13

    Add to cart
    STEX0165

    DESCRIPTION
    Xtreme PTO Clutch
    Exmark 1-603539
    REPLACES OEM
    • Exmark1-601979, 1-603463, 1-603539, 1-611190, 1-611223, 601979, 603463, 603539, 611190, 611223
    • Ferris1521823, 21823, 5021823
    • Scag461074, 481633, 48786
    • Simplicity1521823, 21823, 21823SM, 5021823, 5021823SM
    • Snapper21823, 2840890, 29678, 5021823, 7029678, 7029678YP
    • Snapper Pro21823, 29678, 5021823, 7029678
    • Warner5215-13, 5215-99
    FITS MODELS
  • ExmarkTurf Ranger 1800, Turf Tracer 5-Speed, Serial No. 89,999 and lower and Turf Tracer Hydro, Serial No. 70,000-129,999 and 190,000-319,999
  • Ferris5900027, 5900030, 5901009, 5901012, 5901014, 5901015, 5901194, BGF36K, BGF52K and UltraBelt GD series
  • ScagSSZ, STHM, SW and SWZ series
  • Snapper7080717, 7080682, 7080683, 7080685, 7080686, 7080687 and 7080695
  • Snapper Pro7080682, 7080683, 7080685, 7080686, 7080687, 7080695 and 7080717
    • SPECS
  • Cool Coil Technology
  • Does not fit all applications - Verify part number by referring to model specifications
  • High Temperature Bearing Upgrade
  • Integrated Water Tight, Impact Resistant Wire Harness
  • Replaceable Pulley Bearing
  • Super Smooth "Xtreme Precision" Machined Pulley
  • To prevent premature clutch failure, follow the instruction sheet included with the clutch
  • Belt Width1/2" or 5/8"
  • ID1"
  • Pulley Diameter6"
  • Rotation DirectionClockwise

    • Xtreme PTO Clutch GT2.5-MC04

    Add to cart
    STEX0616

    DESCRIPTION
    Xtreme PTO Clutch
    Exmark 103-0665
    REPLACES OEM
    • Exmark103-0663, 103-0665, 1-641212, 1-641300, 641212, 641300
    • Ferris1521145, 5021145, 5021145SM
    • OguraGT2.5-MC04, GT25MC04, MAGTEXM14, MA-GT-EXM14
    • Scag461395, 461409, 461716
    • Simplicity5021145, 5021145SM
    • Toro641299
    FITS MODELS
  • ExmarkLazer Z series
  • FerrisHydro Drive, HydroWalk DD, HydroWalk and ProCut series
    • SPECS
  • Cool Coil Technology
  • Does not fit all applications - Verify part number by referring to model specifications
  • High Temperature Bearing Upgrade
  • High Torque Cool Coil Upgrade
  • Replaceable Pulley Bearing
  • Super Smooth "Xtreme Precision" Machined Pulley
  • To prevent premature clutch failure, follow the instruction sheet included with the clutch
  • Water Tight, Replaceable Wire Harness Pigtail
  • Belt Width1/2" or 5/8"
  • ID1 1/8"
  • Pulley Diameter6 1/16"
  • Rotation DirectionClockwise

    • Xtreme PTO Clutch GT3.5-MC07

    Add to cart
    STEX0665

    DESCRIPTION
    Xtreme PTO Clutch
    Ogura MA-GT3.5-MC07
    REPLACES OEM
    • OguraGT3.5-MC07, GT35MC07, MA-GT3.5-MC07, MAGT35MC07
    FITS MODELS
  • Ariens992806, 992807 and 992808 Pro-Zoom
  • EverRide992406, 992407 and 992408 Warrior
  • Gravely992220, 992221 and 992222 Pro-Ride
  • ScagTiger Cub and Turf Tiger series
    • SPECS
  • Does not fit all applications - Verify part number by referring to model specifications
  • High Temperature Bearing Upgrade
  • High Torque Cool Coil Upgrade
  • Replaceable Pulley Bearing
  • Super Smooth "Xtreme Precision" Machined Pulley
  • To prevent premature clutch failure, follow the instruction sheet included with the clutch
  • Upgraded to 3 Layer "Xtreme TOUGH" Water Tight, Replaceable Wire Harness
  • Belt Width1/2" or 5/8"
  • ID1 1/8"
  • Pulley Diameter6"
  • Rotation DirectionClockwise

    • Xtreme PTO Clutch GT3.5-VP01R

    Add to cart
    STEX0667

    DESCRIPTION
    Xtreme PTO Clutch
    Ariens 00447100
    REPLACES OEM
    • Ariens00447100
    • Gravely00447100
    • OguraGT3.5-VP01R, GT35VP01R
    SPECS
  • Does not fit all applications - Verify part number by referring to model specifications
  • High Temperature Bearing Upgrade
  • High Torque Cool Coil Upgrade
  • Replaceable Pulley Bearing
  • Super Smooth "Xtreme Precision" Machined Pulley
  • To prevent premature clutch failure, follow the instruction sheet included with the clutch
  • Upgraded to 3 Layer "Xtreme TOUGH" Water Tight, Replaceable Wire Harness
  • Belt Width1/2" or 5/8"
  • ID1 1/8"
  • Pulley Diameter6 7/16"
  • Rotation DirectionCounter Clockwise

    • Xtreme PTO Clutch GT5MC03

    Add to cart
    STEX0815

    DESCRIPTION
    Xtreme PTO Clutch
    Scag 461826
    REPLACES OEM
    • OguraGT5MC03, GT5-MC03, GT5MC04D, GT5-MC04D
    • Scag461662, 461826
    SPECS
  • Does not fit all applications - Verify part number by referring to model specifications
  • FatBoy Series
  • High Temperature Bearing Upgrade
  • High Torque Cool Coil Upgrade
  • Integrated Water Tight Wire Harness
  • Replaceable Pulley Bearing
  • Super Smooth "Xtreme Precision" Machined Pulley
  • To prevent premature clutch failure, follow the instruction sheet included with the clutch
  • Xtreme Torque Series
  • Belt Width1/2" or 5/8"
  • ID1 1/8"
  • Pulley Diameter6"
  • Rotation DirectionClockwise
