Snapper Pro

Xtreme PTO Clutch 5215-13

Add to cart
STEX0165

DESCRIPTION
Xtreme PTO Clutch
Exmark 1-603539
REPLACES OEM
  • Exmark1-601979, 1-603463, 1-603539, 1-611190, 1-611223, 601979, 603463, 603539, 611190, 611223
  • Ferris1521823, 21823, 5021823
  • Scag461074, 481633, 48786
  • Simplicity1521823, 21823, 21823SM, 5021823, 5021823SM
  • Snapper21823, 2840890, 29678, 5021823, 7029678, 7029678YP
  • Snapper Pro21823, 29678, 5021823, 7029678
  • Warner5215-13, 5215-99
FITS MODELS
  • ExmarkTurf Ranger 1800, Turf Tracer 5-Speed, Serial No. 89,999 and lower and Turf Tracer Hydro, Serial No. 70,000-129,999 and 190,000-319,999
  • Ferris5900027, 5900030, 5901009, 5901012, 5901014, 5901015, 5901194, BGF36K, BGF52K and UltraBelt GD series
  • ScagSSZ, STHM, SW and SWZ series
  • Snapper7080717, 7080682, 7080683, 7080685, 7080686, 7080687 and 7080695
  • Snapper Pro7080682, 7080683, 7080685, 7080686, 7080687, 7080695 and 7080717
    • SPECS
  • Cool Coil Technology
  • Does not fit all applications - Verify part number by referring to model specifications
  • High Temperature Bearing Upgrade
  • Integrated Water Tight, Impact Resistant Wire Harness
  • Replaceable Pulley Bearing
  • Super Smooth "Xtreme Precision" Machined Pulley
  • To prevent premature clutch failure, follow the instruction sheet included with the clutch
  • Belt Width1/2" or 5/8"
  • ID1"
  • Pulley Diameter6"
  • Rotation DirectionClockwise

    • Xtreme PTO Clutch 5217-2

    Add to cart
    STEX0002
    DESCRIPTION
    Xtreme PTO Clutch
    Husqvarna 532145028
    REPLACES OEM
    • Ariens03601800
    • AYP145028, 532145028
    • Craftsman145028, 1686882, 1686882S, 1686882SM, 1708536, 1708536SM, 532145028
    • Dixon145028, 532145028
    • Electrolux145028, 532145028
    • Gravely03601800
    • Husqvarna145028, 532145028
    • Kees145028, 532145028
    • Massey Ferguson145028, 1686882, 1686882S, 1686882SM, 532145028
    • McCulloch145028, 1686882, 1686882S, 1686882SM, 532145028
    • Poulan145028, 532145028
    • Simplicity1686882, 1686882S, 1686882SM, 1708536, 1708536SM
    • Snapper1686882, 1686882S, 1686882SM, 1708536, 1708536SM
    • Snapper Pro1686882, 1686882S, 1686882SM
    • Warner5217-2, 5217-46
    FITS MODELS
  • AriensEZR, LT, Sierra and YT series
  • CraftsmanCO, CT, DB, DPR, PP, PR, QP, RE, RK, YG and YP series
  • GravelyGLT440 and GLT448
  • HusqvarnaGTVH200, 1998-2010, GTVH205, 1999-2010, YTH180, 954140010E, 1998-2006, YTH1342XP, YTH1542XPA, YTH1542XPB, YTH1542XPC, YTH1542XPD, YTH1542XPE, YTH1542XPF, YTH1542XPG, YTH2046A, YTH2046B, YTHK1542XPA, YTHK1542XPB and YTHK1542XPC
  • SearsCO, CT, DB, DPR, PP, PR, QP, RE, RK, YG and YP series
  • Simplicity400, Coronet, Regent and ZT series
  • SnapperRT1330, RT1330E and RT1330E Hydro
  • Snapper ProRT1330, 30" deck, hydro drive series 0
    • SPECS
  • Cool Coil Technology
  • Does not fit all applications - Verify part number by referring to model specifications
  • Heavy Duty "FatBoy Series" Upgrade
  • Integrated Water Tight Wire Harness
  • Replaceable Pulley Bearing
  • Super Smooth "Xtreme Precision" Machined Pulley
  • To prevent premature clutch failure, follow the instruction sheet included with the clutch
  • Belt Width1/2" or 5/8"
  • ID1"
  • Pulley Diameter5 3/8"
  • Rotation DirectionCounter Clockwise

    • Xtreme PTO Clutch 5217-6

    Add to cart
    STEX0600
    DESCRIPTION
    Xtreme Electric PTO Clutch
    Xtreme X0003
    REPLACES OEM:
    Ariens: 03643100
    AYP: 160889, 532160889, 53740
    Bolens: 1772388, 717-1459, 917-1459, GW-1772388
    Craftsman: 03643100, 160889, 1772388, 532160889, 53740, 688EC, 7053740, 7053740S, 7053740SM, 717-1459, 917-1459, GW-1772388
    Cub Cadet: 1772388, 717-1459, 917-1459, GW-1772388
    Dixon: 160889, 532160889
    Electrolux: 160889, 532160889
    Exmark: 104-3334
    Gravely: 03643100
    Huskee: 1772388, 717-1459, 917-1459, GW-1772388
    Husqvarna: 160889, 532160889
    John Deere: AM119683
    Jonsered: 160889, 532160889
    Kees: 160889
    Massey Ferguson: 160889, 1772388, 532160889, 7053740, 717-1459, 917-1459
    McCulloch: 160889, 1772388, 532160889, 7053740, 717-1459, 917-1459
    MTD: 1772388, 717-1459, 917-1459, GW-1772388
    Poulan: 160889, 532160889
    Roper: 160889, 532160889
    Snapper: 53740, 7053740, 7053740S, 7053740SM
    Snapper Pro: 7053740
    Swisher: 688EC
    Toro: 104-3334
    Troy-Bilt: 1772388, 717-1459, 917-1459, GW-1772388
    Warner: 5217-35, 5217-6, 5217-7, 5217-9
    White: 1772388, 717-1459, 917-1459, GW-1772388
    Woods: 03643100
    Xtreme: X0003
    Yazoo: 160889, 532160889
    FITS MODELS:
    Ariens: EZR, LT and YT series; Mini Zoom, Sierra, Sport Zoom and Zoom series
    Exmark: Quest, 42" deck, Serial No. 790,000 and higher
    Gravely: EZR, LT and YT series; Mini Zoom, Sierra, Sport Zoom and Zoom series
    Husqvarna: LTH15, LTH130-LTH160, YTH1542A, YTH1542B, YTH1542D, YTH1542E, YTH1746A, YTH1746B, YTHK1542A, YTHK1542B and YTHK1746B
    John Deere: STX38 and STX46, Serial No. 270,000 and lower, black deck
    Snapper: LT145H, hydro series C, LT160H, hydro series C. D, E, F, G, H, LT180H, hydro series D, F, G, H, I, Yard Cruiser series 0, 1 and 2, YT Yard Cruiser, series 1 and 2, 33" and 38" deck
    Toro: DH-150, DH-170, DH-190, DH-200, DH-210, DH-220, RZT480H, Serial No. 280000001-290999999, Timecutter 14-38Z, 16-38Z, 16-42Z, Z4200, Serial No. 230000001-2409999999, Timecutter Z420, Serial No. 250000001-270999999, Timecutter Z4220 and Z4202, Serial No. 280000001-2909999999, ZD420 and ZD420T, Serial No. 260000001-311999999
    Troy-Bilt: LTX13095, LTX13102, LTX13103, LTX13105, LTX13123 and LTX13104
    Woods: R1540

    Xtreme PTO Clutch 5218-221

    Add to cart
    STEX0245

    DESCRIPTION
    Xtreme PTO Clutch
    Simplicity 5100084SM
    REPLACES OEM
    • Craftsman5100084, 5100084S, 5100084SM
    • Ferris5100084, 5100084S, 5100084SM
    • Massey Ferguson5100084, 5100084S, 5100084SM
    • McCulloch5100084, 5100084S, 5100084SM
    • Simplicity5100084, 5100084S, 5100084SM
    • Snapper5100084, 5100084S, 5100084SM
    • Snapper Pro5100084, 5100084S, 5100084SM
    • Warner5218-221
    FITS MODELS
  • FerrisEvolution with 36", 48" and 52" deck, F50XT series with 36" deck, F150XT series with 52", F200XT series with 61" deck, Flail series, IS1500Z, IS1500ZX, IS2000Z and Procut S series
  • Massey Ferguson3000 and 3900 series
  • SimplicityCitation Series 5900522, 5900523, 5900524, 5900525, 5900526, 5900527, 5900530, 5900531, 5900762, 5900764, 5900820, 5900821, 5900954 and 2690479
  • SnapperS50X, S50XT, S75X, S125XT, S150X, S200X, S200XT, SW30KAV and SW35KAV series
  • Snapper ProS50XT, S75XT, S150XT, S200XT and SW30 series
    • SPECS
  • Cool Coil Technology
  • Does not fit all applications - Verify part number by referring to model specifications
  • Heavy Duty "FatBoy Series" Upgrade
  • Replaceable Pulley Bearing
  • Super Smooth "Xtreme Precision" Machined Pulley
  • To prevent premature clutch failure, follow the instruction sheet included with the clutch
  • Upgraded to 3 Layer "Xtreme TOUGH" Integrated, Water Tight Wire Harness
  • Belt Width1/2" or 5/8"
  • ID1 1/8"
  • Pulley Diameter6 5/16"
  • Rotation DirectionCounter Clockwise

    • Xtreme PTO Clutch 5218-26

    Add to cart
    STEX0043

    DESCRIPTION
    Xtreme PTO Clutch
    Grasshopper 606242
    REPLACES OEM
    • Craftsman35520, 58925, 7058925, 7058925YP
    • Grasshopper388767, 388769, 606242
    • Kees7058925
    • Massey Ferguson58925, 7058925
    • McCulloch58925, 7058925
    • Snapper35520, 58925, 7058925, 7058925YP
    • Snapper Pro58925, 7058925
    • Warner5218-147, 5218-170, 5218-214, 5218-226, 5218-257, 5218-26, 5218-58, 5218-67
    • Woods388767, 388769, 58925, 606242, 7058925, 73558, 74075
    FITS MODELS
  • Grasshopper618, 718K, 720K, 721, 721D, 721D2, 721DH2, 721G2, 722D2, 723KH2, 725, 725A, 725G2, 725K, 725K2, 729G2, 928G2 and 932G2
  • SnapperEZF, MZM, ZF, ZM and ZMT series
  • Snapper ProEZF, MZM, ZF, ZM and ZMT series
  • WoodsF21D, FZ21D, FZ23B and FZ28K, Serial No. 1174789 and higher, FZ25D; and Mow 'n Machines 6182, 6200, 6215, 6250, F23, F25, F25L and F27
    • SPECS
  • Cool Coil Technology
  • Does not fit all applications - Verify part number by referring to model specifications
  • High Temperature Bearing Upgrade
  • Replaceable Pulley Bearing
  • Super Smooth "Xtreme Precision" Machined Pulley
  • To prevent premature clutch failure, follow the instruction sheet included with the clutch
  • Upgraded to 3 Layer "Xtreme TOUGH" Integrated, Water Tight, Impact resistant Wire Harness
  • Belt WidthDouble A
  • ID1 1/8"
  • Pulley Diameter4 7/8"
  • Rotation DirectionClockwise

    • Xtreme PTO Clutch GT2.5-SN01

    Add to cart
    STEX0600

    DESCRIPTION
    Xtreme PTO Clutch
    Snapper 7075672YP
    REPLACES OEM
    • OguraGT2.5-SN01, GT25SN01
    • Simplicity7075672YP
    • Snapper7075081, 7075672, 7075672YP, 75672
    • Snapper Pro7075081, 7075672, 7075672YP
    FITS MODELS
  • SnapperPro series 1, 2 and 3 Joystick
    • SPECS
  • Cool Coil Technology
  • Does not fit all applications - Verify part number by referring to model specifications
  • High Temperature Bearing Upgrade
  • Replaceable Pulley Bearing
  • Super Smooth "Xtreme Precision" Machined Pulley
  • To prevent premature clutch failure, follow the instruction sheet included with the clutch
  • Upgraded to 3 Layer "Xtreme TOUGH" Water Tight, Replaceable Wire Harness
  • Belt Width1/2" or 5/8"
  • ID1"
  • Pulley Diameter6"
  • Rotation DirectionCounter Clockwise

    • Xtreme PTO Clutch GT-JD11

    Add to cart
    STEX0487

    DESCRIPTION
    Xtreme PTO Clutch
    Snapper 1757359YP
    REPLACES OEM
    • Ferris1757359
    • Murray1757359YP
    • OguraMAGTJD11, MA-GT-JD11
    • Simplicity1757359YP
    • Snapper1757359YP
    • Snapper Pro1757359
    FITS MODELS
  • Ferris5900111, 5900543, 5900544, 5900545, 5900546, 5900604, 5900962, 5900963, 5900989, 5900990 and 5901037
  • SimplicityAxion 78007600, 7800380 and 7800360
  • Snapper2691043-03, 2691043-04, 2691166-00, 2691136-00, 2691136-01, 2691135-00, 2691137-00, 2691137-01, 2691164-00, 2691165-00 and 2691167-00
  • Snapper Pro5900895 and 5900896 SW series, Serial No. 2016545302 and lower
    • SPECS
  • Does not fit all applications - Verify part number by referring to model specifications
  • Heavy Duty "FatBoy Series" Upgrade
  • High Torque Cool Coil Upgrade
  • Integrated Water Tight Wire Harness
  • Replaceable Pulley Bearing
  • Super Smooth "Xtreme Precision" Machined Pulley
  • To prevent premature clutch failure, follow the instruction sheet included with the clutch
  • Belt Width1/2" or 5/8"
  • ID1"
  • Pulley Diameter5 5/16"
  • Rotation DirectionCounter Clockwise
