Toro

Xtreme PTO Clutch 5210-33

Add to cart
STEX0185

DESCRIPTION
Xtreme PTO Clutch
MTD 917-3497
REPLACES OEM
  • AGCO1703816SM
  • Bolens717-0983, 717-3497, 917-0983, 917-3497
  • CaseIH990947
  • Craftsman16343, 1703816SM, 19982, 53679, 7016343, 7053679, 717-0983, 717-3497, 917-0983, 917-3497
  • Cub Cadet717-0983, 717-0983P, 717-3497, 917-0983, 917-3497
  • Ingersoll Rand990947
  • Jacobsen990947
  • King Cat232201
  • MTD1755341P, 717-0983, 717-0983P, 717-3497, 917-0983, 917-3497
  • Simplicity1703816, 1703816SM, 71703816
  • Snapper16343, 19982, 53679, 7016343, 7053679, 7053679YP
  • Toro113426, 11346, 99-8012
  • Troy-Bilt717-3036, 717-3497, 917-3497, 959-3230
  • Warner5210-33, 5215-59
  • White717-0983, 717-3497, 917-0983, 917-3497
FITS MODELS
  • BolensFST14, FST15, LR13, LT14, LT145, LT15, LT16 and LT165
  • Cub Cadet1110, 1105, 1215, 1220, 1225, 1325, 1405, 1415, 1420, 1605, 1610, 1615, 1620, 1715, 1720 and 1730
  • Ford9800686
  • Lawn-Boy156729, 52140, 52144A, 52145A, 52153, 52161, 52163, 52163A and 52164, 1991-1992
  • MTDFST14, FST15, LT13, LT14, LT15, LT16, LT145 and LT165
  • Simplicity1613G, 1613H, 1615G, 1615H, 1616H, 2614H, 2616H, LT, LTG and LTH series
  • SnapperGT180, GYT, HT, LT, RYT and YT series
    • SPECS
  • Cool Coil Technology
  • Does not fit all applications - Verify part number by referring to model specifications
  • High Temperature Bearing Upgrade
  • Integrated Water Tight Wire Harness
  • Replaceable Pulley Bearing
  • Super Smooth "Xtreme Precision" Machined Pulley
  • To prevent premature clutch failure, follow the instruction sheet included with the clutch
  • Belt Width1/2" or 5/8"
  • ID1"
  • Pulley Diameter5 5/16"
  • Rotation DirectionCounter Clockwise

    • Xtreme PTO Clutch 5210-34

    Add to cart
    STEX0196
    DESCRIPTION
    Xtreme PTO Clutch
    Ariens 03450500
    REPLACES OEM
    • Ariens03450500, 050236, 3450500
    • Dixie Chopper50300
    • Exmark116277
    • Gravely03450500, 050236
    • Snapper7079197, 7079446, 7079446YP, 79197, 7-9197, 79446, 7-9446
    • Toro116277
    • Warner5210-34, 5210-50, 5215-88
    FITS MODELS
  • Ariens934005, 934006, 934007, 934008, 934019 and 934020, HT series; 49065, 50267, 52271, 52628, 52626, 51385, 513386, 52627, 934010, 934011, 934012, 934013, 934014, 934016, 934017, 934018 and 934022, GEM series
  • Gravely934005, 934006, 934007, 934008, 934019 and 934020, HT series; 49065, 50267, 52271, 52628, 52626, 51385, 513386, 52627, 934010, 934011, 934012, 934013, 934014, 934016, 934017, 934018 and 934022, GEM series
  • SnapperZTR series 0-5
  • Toro612-Z, Serial No. 1000001-1999999, 616-Z and 620-Z, Serial No. 1000001-5999999, 616-Z, Serial No. 3900001-4999999, and Z118, Serial No. 79000001-79999999

    • Xtreme PTO Clutch 5210-52

    Add to cart
    STEX0450
    DESCRIPTION
    Xtreme PTO Clutch
    Grasshopper 604182
    REPLACES OEM
    • Ariens03090800, 30908
    • CaseIHC38410, WD-C38410
    • CraftsmanC38410, WD-C38410
    • Cub CadetC38410, WD-900-5716, WD-C38410
    • Grasshopper388766, 604182
    • Gravely03090800, 30908
    • Ingersoll RandC38410
    • JacobsenC38410
    • MTDC38410, WD-900-5716, WD-C38410
    • Toro93-3160
    • Warner5210-52, 5215-62
    • Woods388766, 604182
    FITS MODELS
  • AriensGrand Sierra, 931037, 931038, 931302 and 931303
  • Grasshopper718D, 718K, 720K, 721, 721D and 725
  • GravelyGT600, 987104
  • Toro74140 and Proline 724-Z, Serial No. 590001-699999
  • WoodsMow 'n Machines
    • SPECS
  • Cool Coil Technology
  • Does not fit all applications - Verify part number by referring to model specifications
  • Heavy Duty "FatBoy Series" Upgrade
  • Replaceable Pulley Bearing
  • Super Smooth "Xtreme Precision" Machined Pulley
  • To prevent premature clutch failure, follow the instruction sheet included with the clutch
  • Upgraded to 3 Layer "Xtreme TOUGH" Integrated, Water Tight Wire Harness
  • Belt WidthDouble A
  • ID1 1/8"
  • Pulley Diameter4 13/16"
  • Rotation DirectionClockwise

    • Xtreme PTO Clutch 5217-6

    Add to cart
    STEX0600
    DESCRIPTION
    Xtreme Electric PTO Clutch
    Xtreme X0003
    REPLACES OEM:
    Ariens: 03643100
    AYP: 160889, 532160889, 53740
    Bolens: 1772388, 717-1459, 917-1459, GW-1772388
    Craftsman: 03643100, 160889, 1772388, 532160889, 53740, 688EC, 7053740, 7053740S, 7053740SM, 717-1459, 917-1459, GW-1772388
    Cub Cadet: 1772388, 717-1459, 917-1459, GW-1772388
    Dixon: 160889, 532160889
    Electrolux: 160889, 532160889
    Exmark: 104-3334
    Gravely: 03643100
    Huskee: 1772388, 717-1459, 917-1459, GW-1772388
    Husqvarna: 160889, 532160889
    John Deere: AM119683
    Jonsered: 160889, 532160889
    Kees: 160889
    Massey Ferguson: 160889, 1772388, 532160889, 7053740, 717-1459, 917-1459
    McCulloch: 160889, 1772388, 532160889, 7053740, 717-1459, 917-1459
    MTD: 1772388, 717-1459, 917-1459, GW-1772388
    Poulan: 160889, 532160889
    Roper: 160889, 532160889
    Snapper: 53740, 7053740, 7053740S, 7053740SM
    Snapper Pro: 7053740
    Swisher: 688EC
    Toro: 104-3334
    Troy-Bilt: 1772388, 717-1459, 917-1459, GW-1772388
    Warner: 5217-35, 5217-6, 5217-7, 5217-9
    White: 1772388, 717-1459, 917-1459, GW-1772388
    Woods: 03643100
    Xtreme: X0003
    Yazoo: 160889, 532160889
    FITS MODELS:
    Ariens: EZR, LT and YT series; Mini Zoom, Sierra, Sport Zoom and Zoom series
    Exmark: Quest, 42" deck, Serial No. 790,000 and higher
    Gravely: EZR, LT and YT series; Mini Zoom, Sierra, Sport Zoom and Zoom series
    Husqvarna: LTH15, LTH130-LTH160, YTH1542A, YTH1542B, YTH1542D, YTH1542E, YTH1746A, YTH1746B, YTHK1542A, YTHK1542B and YTHK1746B
    John Deere: STX38 and STX46, Serial No. 270,000 and lower, black deck
    Snapper: LT145H, hydro series C, LT160H, hydro series C. D, E, F, G, H, LT180H, hydro series D, F, G, H, I, Yard Cruiser series 0, 1 and 2, YT Yard Cruiser, series 1 and 2, 33" and 38" deck
    Toro: DH-150, DH-170, DH-190, DH-200, DH-210, DH-220, RZT480H, Serial No. 280000001-290999999, Timecutter 14-38Z, 16-38Z, 16-42Z, Z4200, Serial No. 230000001-2409999999, Timecutter Z420, Serial No. 250000001-270999999, Timecutter Z4220 and Z4202, Serial No. 280000001-2909999999, ZD420 and ZD420T, Serial No. 260000001-311999999
    Troy-Bilt: LTX13095, LTX13102, LTX13103, LTX13105, LTX13123 and LTX13104
    Woods: R1540

    Xtreme PTO Clutch 5218-10

    Add to cart
    STEX0041

    DESCRIPTION
    Xtreme PTO Clutch
    Gravely 09225400
    REPLACES OEM
    • Ariens092254, 09225400, 592003, 59200300
    • AYP128711, 539128711
    • Country ClipperE-6247
    • Craftsman128711, 539128711
    • Dixon128711, 539128711, 60473, 60499, 61516
    • Electrolux128711, 539128711
    • Exmark94-6136
    • Gravely092026, 092080, 092254, 09225400, 592003, 59200300
    • Husqvarna128711, 539128711
    • Kees128711, 539128711
    • Massey Ferguson128711, 539128711
    • McCulloch128711, 539128711
    • Poulan128711, 539128711
    • Toro94-6136
    • Warner5218-10, 5218-223, 5218-224
    FITS MODELS
  • AriensHydro Pro 300 and ZTR PM 200
  • Country ClipperSR1010, SR1015 and SR1020 Charger models; Jazee SR205 and SR355, 2007-2008, Jazee SR210 and SR360, 2009, Jazee SR215 and SR365, 2010, Jazee SR220 and SR370, 2011, Boss SR1200, 2006 and Zeton
  • DixonZTR6023, ZTR7025 and ZTR7225
  • GravelyPM and Pro 300 series
    • SPECS
  • Cool Coil Technology
  • Does not fit all applications - Verify part number by referring to model specifications
  • High Temperature Bearing Upgrade
  • Replaceable Pulley Bearing
  • Super Smooth "Xtreme Precision" Machined Pulley
  • To prevent premature clutch failure, follow the instruction sheet included with the clutch
  • Upgraded to 3 Layer "Xtreme TOUGH" Integrated, Water Tight Wire Harness
  • Belt Width1/2" or 5/8"
  • ID1 1/8"
  • Pulley Diameter5 3/8"
  • Rotation DirectionCounter Clockwise

    • Xtreme PTO Clutch 5218-100

    Add to cart
    STEX0257

    DESCRIPTION
    Xtreme PTO Clutch
    Exmark 103-6590
    REPLACES OEM
    • Exmark103-3131, 103-3245, 103-6590
    • Toro103-3131, 103-3245, 103-6590
    • Warner5218-100, 5218-228, 5218-243
    FITS MODELS
  • ExmarkLazer Z AC and AS, Serial No. 440,000 and higher
  • ToroZ Master Z500, Z528 and Z553
    • SPECS
  • Cool Coil Technology
  • Does not fit all applications - Verify part number by referring to model specifications
  • Heavy Duty "FatBoy Series" Upgrade
  • Replaceable Pulley Bearing
  • Super Smooth "Xtreme Precision" Machined Pulley
  • To prevent premature clutch failure, follow the instruction sheet included with the clutch
  • Upgraded to 3 Layer "Xtreme TOUGH" Integrated, Water Tight Wire Harness
  • Belt Width1/2" or 5/8"
  • ID1"
  • Pulley Diameter7 3/16"
  • Rotation DirectionClockwise

    • Xtreme PTO Clutch 5218-101

    Add to cart
    STEX0460

    DESCRIPTION
    Xtreme PTO Clutch
    Exmark 109-7666
    REPLACES OEM
    • Exmark103-2453, 103-3244, 103-6589, 109-7666
    • Toro103-2453, 103-3244, 103-6589, 109-7666
    • Warner5218-101, 5218-217
    FITS MODELS
  • ExmarkLazer Z XS, Serial No. 440,000 and higher; Lazer Z AS, Serial No. 720,000-789,999; Lazer Z, Kawasaki units, Serial No. 370,000 and higher; and Lazer Z XS, Serial No. 600,000 and higher
  • ToroZ Master Z550, Serial No. 280000001-280999999, Z555, Serial No. 240000001-250999999, Z558, Serial No. 270000001-270999999 and Z587L, Serial No. 240000001-240999999
    • SPECS
  • Cool Coil Technology
  • Does not fit all applications - Verify part number by referring to model specifications
  • Heavy Duty "FatBoy Series" Upgrade
  • Replaceable Pulley Bearing
  • Super Smooth "Xtreme Precision" Machined Pulley
  • To prevent premature clutch failure, follow the instruction sheet included with the clutch
  • Upgraded to 3 Layer "Xtreme TOUGH" Integrated, Water Tight, Impact resistant Wire Harness
  • Belt Width1/2" or 5/8"
  • ID1 1/8"
  • Pulley Diameter7 1/8"
  • Rotation DirectionClockwise

    • Xtreme PTO Clutch 5218-161

    Add to cart
    STEX0238

    DESCRIPTION
    Xtreme PTO Clutch
    Exmark 109-6627
    REPLACES OEM
    • Exmark103-0011, 103-0083, 109-6626, 109-6627
    • Toro103-0011, 103-0083, 109-6626, 109-6627
    • Warner5218-161, 5218-206, 5218-313, 5218-82
    FITS MODELS
  • ExmarkFront Runner, air cooled and diesel, Serial No. 600,000 and higher; and Lazer Z XP, Serial No. 260,000-599,999
  • ToroZ590-D, Serial No. 280000000-311999999 and Z597-D, Serial No. 240000000-270999999
    • SPECS
  • Cool Coil Technology
  • Does not fit all applications - Verify part number by referring to model specifications
  • High Temperature Bearing Upgrade
  • Replaceable Pulley Bearing
  • Super Smooth "Xtreme Precision" Machined Pulley
  • To prevent premature clutch failure, follow the instruction sheet included with the clutch
  • Upgraded to 3 Layer "Xtreme TOUGH" Integrated, Water Tight, Impact resistant Wire Harness
  • Belt WidthDouble A
  • ID1 1/8"
  • Pulley Diameter6 1/2"
  • Rotation DirectionClockwise

    • Xtreme PTO Clutch 5218-207

    Add to cart
    STEX0239

    DESCRIPTION
    Xtreme PTO Clutch
    Toro 116-1620
    REPLACES OEM
    • Exmark109-9282, 116-1604, 116-1620
    • Toro109-9282, 116-1604, 116-1620
    • Warner5218-207
    FITS MODELS
  • ExmarkLazer Z S, E and X series, Serial No. 312,000 and higher, Next Lazer Z, air cooled, Serial No. 790,000 and higher, Next Lazer Z ASX, Serial No. 850,000 and higher, and Quest SP, Serial No. 850,000 and higher
  • ToroZ Master G3 turbo force, Serial No. 290000001-312999999, 48", 52", 60" and 72" decks
    • SPECS
  • Cool Coil Technology
  • Does not fit all applications - Verify part number by referring to model specifications
  • Heavy Duty "FatBoy Series" Upgrade
  • Replaceable Pulley Bearing
  • Super Smooth "Xtreme Precision" Machined Pulley
  • To prevent premature clutch failure, follow the instruction sheet included with the clutch
  • Upgraded to 3 Layer "Xtreme TOUGH" Integrated, Water Tight Wire Harness
  • Belt Width1/2" or 5/8"
  • ID1 1/8"
  • Pulley Diameter7 3/16"
  • Rotation DirectionCounter Clockwise

    • Xtreme PTO Clutch 5218-21

    Add to cart
    STEX0042

    DESCRIPTION
    Xtreme PTO Clutch
    Exmark 103-0662
    REPLACES OEM
    • Exmark103-0500, 103-0661, 103-0662, 1-631644, 1-631731, 1-633098, 631644, 631731, 633098, E631644, E631731, E633098
    • Toro103-0500, 103-0661, 103-0662, 1-631644, 1-631731, 1-633098, 1-641213, 631644, 631731, 633098, E631644, E631731, E633098
    • Warner5218-21, 5218-25, 5218-293, 5218-76, 5218-76C
    FITS MODELS
  • ExmarkLazer Z, Serial No. 789,999 and lower; Turf Tracer Hydro, Serial No. 320,000 and higher; Turf Tracer S, Serial No. 920,000 and higher; and Turf Tracer X, Serial No. 920,000 and higher
    • SPECS
  • Cool Coil Technology
  • Does not fit all applications - Verify part number by referring to model specifications
  • Does NOT replace Ogura clutches
  • Heavy Duty "FatBoy Series" Upgrade
  • Replaceable Pulley Bearing
  • Super Smooth "Xtreme Precision" Machined Pulley
  • To prevent premature clutch failure, follow the instruction sheet included with the clutch
  • Upgraded to 3 Layer "Xtreme TOUGH" Integrated, Water Tight, Impact resistant Wire Harness
  • Belt Width1/2" or 5/8"
  • ID1"
  • Pulley Diameter6 5/16"
  • Rotation DirectionClockwise

    • Xtreme PTO Clutch 5218-300

    Add to cart
    STEX0716

    DESCRIPTION
    Xtreme PTO Clutch
    Exmark 130-1848
    REPLACES OEM
    • Exmark116-4172, 130-1848
    • Toro116-4172, 130-1848
    FITS MODELS
  • ExmarkVT25EKC524, Serial No. 920,000 and higher and VT730EKC524 and VT740EKC604, Serial No. 312,000 and higher Vantage series
    • SPECS
  • Does not fit all applications - Verify part number by referring to model specifications
  • To prevent premature clutch failure, follow the instruction sheet included with the clutch
  • Xtreme Torque Series
  • Belt Width1/2" or 5/8"
  • ID1 1/8"
  • Pulley Diameter7 1/4"
  • Rotation DirectionCounter Clockwise

    • Xtreme PTO Clutch 5218-5

    Add to cart
    STEX0015

    DESCRIPTION
    Xtreme PTO Clutch
    Exmark 103-0664
    REPLACES OEM
    • AYP102603, 109580, 539102603, 539109580
    • Bobcat1522040, 2188151
    • Bunton2188151
    • CaseIH2188151
    • Craftsman102603, 109580, 2188151, 539102603, 539109580
    • Dixon102603, 109580, 539102603, 539109580
    • Electrolux102603, 109580, 539102603, 539109580
    • Exmark103-0664, 1-631645, 1-633099, 631645, 633099, E633099
    • Ferris1522040
    • Husqvarna102603, 109580, 539102603, 539109580
    • Ingersoll Rand2188151
    • Jacobsen2188151
    • Jonsered102603, 539102603
    • Kees102603, 109580, 539102603, 539109580
    • Massey Ferguson102603, 109580, 539102603, 539109580
    • McCulloch102603, 109580, 539102603, 539109580
    • Poulan102603, 109580, 539102603, 539109580
    • Ransomes2188151
    • Roper102603, 109580, 539102603, 539109580
    • Toro103-0664, 103-0665, 1-631645, 1-633099, 631645, 633099, E633099
    • Warner5218-259, 5218-5
    • Woods2188151
    FITS MODELS
  • BobcatZT200 and ZT331 series
  • ExmarkLazer Z, Serial No. 159,999 and lower
  • HusqvarnaZTH5223A and ZTH5225A, 2000-2006
  • KeesZKH52220, ZKH52221, ZKH52222, ZKH52223, ZKH52233, ZKH52250 and ZKH52251
    • SPECS
  • Cool Coil Technology
  • Does not fit all applications - Verify part number by referring to model specifications
  • Heavy Duty "FatBoy Series" Upgrade
  • Replaceable Pulley Bearing
  • Super Smooth "Xtreme Precision" Machined Pulley
  • To prevent premature clutch failure, follow the instruction sheet included with the clutch
  • Upgraded to 3 Layer "Xtreme TOUGH" Integrated, Water Tight, Impact resistant Wire Harness
  • Belt Width1/2" or 5/8"
  • ID1 1/8"
  • Pulley Diameter6 5/16"
  • Rotation DirectionClockwise

    • Xtreme PTO Clutch 5218-65

    Add to cart
    STEX0049

    DESCRIPTION
    Xtreme PTO Clutch
    Exmark 103-0665
    REPLACES OEM
    • Bobcat2721337
    • Bunton2721337
    • CaseIH2721337
    • Craftsman2721337
    • Exmark103-0501, 103-0665, 1-631732, 631732, E631732
    • Great Dane180265
    • Ingersoll Rand2721337
    • Jacobsen2721337
    • Ransomes2721337
    • Toro103-0501, 103-0665, 1-631732, 631732, E631732
    • Warner5218-213, 5218-225, 5218-65, 5218-65E
    • Woods2721337
    FITS MODELS
  • Bobcat942218E, 942219F, Predator Pro, ProCat, ZT100, ZT200D, ZT218, ZT219, ZT220ES, ZT223, ZT225, ZT226, ZT226ES, ZT226EFI, ZT227 and ZT228
  • ExmarkLazer Z and Lazer Z EFI, Serial No. 160,000-369,999
  • WoodsME1952K, ME2661B, MZ1952K, MZ2061YD, MZ2252K, MZ2561K, MZ2652G, MZ3361G, MZ2661K, MZ2661KL and MZ2761
    • SPECS
  • Cool Coil Technology
  • Does not fit all applications - Verify part number by referring to model specifications
  • Heavy Duty "FatBoy Series" Upgrade
  • Replaceable Pulley Bearing
  • Super Smooth "Xtreme Precision" Machined Pulley
  • To prevent premature clutch failure, follow the instruction sheet included with the clutch
  • Upgraded to 3 Layer "Xtreme TOUGH" Integrated, Water Tight Wire Harness
  • Belt Width1/2" or 5/8"
  • ID1 1/8"
  • Pulley Diameter6 5/16"
  • Rotation DirectionClockwise

    • Xtreme PTO Clutch 5218-73

    Add to cart
    STEX0314

    DESCRIPTION
    Xtreme PTO Clutch
    Exmark 103-1364
    REPLACES OEM
    • Exmark103-0281, 103-1364
    • Toro103-0281, 103-1364
    • Warner5218-73
    FITS MODELS
  • ExmarkLazer Z, Kawasaki, Serial No. 260,000-369,999 and Lazer Z, liquid-cooled, Serial No. 260,000-369,999
    • SPECS
  • Cool Coil Technology
  • Does not fit all applications - Verify part number by referring to model specifications
  • Heavy Duty "FatBoy Series" Upgrade
  • Replaceable Pulley Bearing
  • Super Smooth "Xtreme Precision" Machined Pulley
  • To prevent premature clutch failure, follow the instruction sheet included with the clutch
  • Upgraded to 3 Layer "Xtreme TOUGH" Integrated, Water Tight, Impact resistant Wire Harness
  • Belt Width1/2" or 5/8"
  • ID1 1/8"
  • Pulley Diameter6 5/16"
  • Rotation DirectionClockwise

    • Xtreme PTO Clutch 5218-99

    Add to cart
    STEX0461

    DESCRIPTION
    Xtreme PTO Clutch
    Exmark 116-1611
    REPLACES OEM
    • Exmark103-3132, 103-3246, 103-4000, 103-4057, 103-5835, 103-6579, 109-7665, 109-7673, 116-1611
    • Toro103-3132, 103-3246, 103-4000, 103-4057, 103-5835, 103-6579, 109-7665, 109-7673, 116-1611
    • Warner5218-168, 5218-202, 5218-209, 5218-99
    FITS MODELS
  • ExmarkLazer Z AC EFI, Serial No. 440,000 and higher, Lazer Z air cooled EFI, Serial No. 720,000 and higher, Lazer Z AS EFI, Serial No. 510,000-789,999, Lazer Z AS, Serial No. 510,000-719,999 and Lazer Z EFI, Serial No. 370,000-439,999
  • ToroZ Master Z500, Serial No. 280000001-311999999, Z557, Serial No. 240000001-260999999, Z560, Serial No. 270000001-270999999 and Z 5588E, Serial No. 240000001-260999999
    • SPECS
  • Cool Coil Technology
  • Does not fit all applications - Verify part number by referring to model specifications
  • Heavy Duty "FatBoy Series" Upgrade
  • Integrated Water Tight Wire Harness
  • Replaceable Pulley Bearing
  • Super Smooth "Xtreme Precision" Machined Pulley
  • To prevent premature clutch failure, follow the instruction sheet included with the clutch
  • Belt Width1/2" or 5/8"
  • ID1 1/8"
  • Packaging typeBranded box
  • Pulley Diameter7 1/8"
  • Rotation DirectionClockwise
